Product / TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor
TMC55-OD 55“ Outdoor High-Brightness Monitor

TMC55-OD 55“ Outdoor High-Brightness Monitor

• Ambient light sensor for auto brightness adjustment
• Brightness output of 2500 nits
• Ingress protection: IP65 rating
• IK10 tempered cover glass
• Full HD resolution @ 60Hz refresh rate
• VESA mount supported

Description
Specifications
Resources

Vantron TMC55-OD 55-inch outdoor high-brightness monitor delivers exceptional sunlight-readable visuals and robust all-weather durability, perfectly suited for applications such as outdoor digital signage, public facilities, and smart city deployments. Its IP65-rated design ensures continuous 24/7 operation in harsh environments.

The monitor features a 2500-nit high-brightness panel with full HD 1080p resolution, enhanced by optically bonded anti-reflective coverglass and an ambient light sensor for automatic brightness adjustment to ensure clear visibility even in direct sunlight, while its Quarter Wave Plate polarizer supports both portrait and landscape orientations for flexible installation. Built for durability, it comes with IK10 tempered glass, an efficient thermal exhaust system, and an operating temperature range of -20°C to 60°C to protect against vandalism, extreme heat, and the elements, with remote monitoring via an IP interface and an anti-theft gyroscopic sensor further enhancing reliability and security; it also features a standard VESA mounting pattern for versatile, cost-effective outdoor installations.

Specifications
Product Name
TMC55-OD 55” Outdoor High-Brightness Monitor (Large-size Touch Display)
Diagonal size
55"
Aspect ratio
16:9
Resolution
1920 x 1080 @ 60Hz
Brightness (Typical)
2500 nits
Active area
1211.6 x 682.4mm
Contrast ratio
1200:1
Number of colors
16.7M (True 8-bit)
Response time
8ms (Gray to Gray)
Viewing angle
178° Vertical/Horizontal
Pixel pitch
0.63 x 0.63mm
Color gamut
70% NTSC
LCD
High-TNI LCD, 105°C-rated
Cover glass
IK10 rated, tempered
Surface treatment
Anti-glare
Hardness
6H
Backlight adjustment
Automatic (via ambient light sensor) & RS232 control
Display orientation
Landscape/Portrait mode (requires HDMI source rotation)
Operation mode
24/7 continuous operation
Touch Panel
Optional
I/O
1 x HDMI (supports 480i/p, 720p, 1080i/p); 1 x RS232 (DB9)
Sensor
1 x Ambient light sensor extender (reserved)
Dimensions
1278.29mm x 749.08mm x 110.81mm
Gross weight
70kg
Installation
VESA mount (400mm x 400mm)
IP rating
IP65
Heat dissipation
heatsink
Power input
100 ~ 240V AC, 50 ~ 60Hz
Power consumption
Typical: 260W; Max: 300W
Standby power
<0.3W (passive mode); <0.5W (active mode)
Operating temperature
-20℃ ~ +60℃
Operating humidity
10% ~ 80%RH (non-condensing)
Certification
CCC, FCC, CE

Resources

Docs
Products
News & Blog

Vantron TMC55-OD 55“ Outdoor High-Brightness Display Monitor Datasheet
