VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC
VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC

VT-DISP37-3568 37'' Bar-type Android All-in-one Panel PC

● Quad-core Cortex-A55 processor, up to 2.0GHz
● Large active area with a resolution of 1920 × 560
● USB 2.0 Type-A, Micro-USB, TF card slot for expansion
● ETH, optional Wi-Fi 5 / BT 5.0 for communication
● Android operating system
● VESA patterns (280 × 3 × 160mm) for simplified installation

Description
Specifications
Resources

VT-DISP37-3568 bar-type all-in-one panel PC is powered by the high-performing processor that has four cores capable of delivering high computing power while keeping the CPU power consumption low. The device features a resolution of 1920 × 560 pixels and a brightness of up to 500/700 nits, delivering an excellent visual experience.

VT-DISP37-3568 provides an Ethernet port and optional Wi-Fi 5/ Bluetooth 5.0, ensuring stable for stable and reliable network connection. VT-DISP35-3568 is equipped with one USB 2.0 Type-A port and one Micro-USB 2.0 port, allowing debugging and peripherals connection. Storage capacity can be expanded via TF card. Moreover, the device is designed with VESA hole patterns to simplify mounting. These features make it ideal for scenarios such as commercial display, industrial control, and smart terminals.

Specifications
Product Name
VT-DISP37-3568 Bar-type Android All-in-one Panel PC
CPU
Quad-core Cortex-A55 processor, up to 2.0GHz
Memory
2GB LPDDR4X
Storage
16GB eMMC
Ethernet
1 × Ethernet port, 10/100Mbps
Wi-Fi/BT
Optional: 802.11 a/b/g/n/ac, Bluetooth 5.0
Screen Size
900.90mm × 254.20mm
Resolution
1920 × 560 pixels
Brightness
500/700 nits
Active Area
899.712mm × 253.044mm
USB
1 × USB 2.0 Type-A | 1 × Micro-USB 2.0
TF
1 × TF card slot
RTC
Supported
Watchdog
Supported
OS
Android 11
Button
1 × Reset button (Short press to restart, long press to restore factory settings)
Input
1 × Power jack, 12V⎓5A (inner diameter: 2.5mm, outer diameter: 5.5mm)
Dimensions
918.90mm × 284.90mm × 38mm
Weight
10 kg
Installation
VESA mounting
Temperature
Operating: 0℃~+50℃ | Storage: -20℃~+60℃
Humidity
Operating: 20%~80% RH (Non-condensing)
