O15 15.6” RK3399 Android All-in-one Panel PC

O15 15.6” RK3399 Android All-in-one Panel PC

Features

◆ RK3399, Cortex-A72 dual-core and Cortex-A53 quad-core high-performance processor

◆ 2GB Memory and 16GB Storage

◆ 15.6” 1920 x 1080 FHD display, 10-point PCAP touch panel

◆ USB Type-C, USB Type-A supported

◆ PoE supported

◆ VESA mount option available

Description

Specifications

Documentation

Vantron O15 15.6” all-in-one panel PC is powered by RK3399 high-performance hex-core processor. O15 integrates a 15.6-inch intuitive, reliable touchscreen monitor with a compact, all-purpose industrial computer, and demonstrates high reliability and high performance. It offers excellent visual experience and enhances human-machine interaction. With varying specification options, O15 is customizable to allow application in commercial displays, self-service terminals, game machines, and industrial automation.

Specifications

CPU

Rockchip RK3399, Dual core ARM Cortex A72 and Quad core ARM Cortex A53, 1.8GHz (Max)

Memory

2GB

Storage

16GB

Ethernet

1 x RJ45, 10/100/1000Mbps (PoE supported)

Wi-Fi & BT

Wi-Fi 802.11 ac/a/b/g/n + BT 5.0

Display

15.6" LCD Resolution: 1920 x 1080 Brightness: 250 cd/m2

10-point PCAP touch screen

Audio

1 x 3.5mm combo audio jack

Camera

Front camera, 5MP

USB

1 x USB 3.0 Type-C 2 x USB 2.0 Type-A

Debug

1 x Debug COM port (RS232)

Button

1 x Recovery button

Input

12V/2A DC

Dimensions

399mm x 249mm x 36.7mm

Temperature

Operating: 0℃~+50℃ Storage: -20℃~+60℃

Installation

VESA mount (75mm x 75mm)

Android 10

Device management platform

BlueSphere MDM

Documentation

O15 15.6” All-in-one Panel PC Datasheet
