Features

◆ Android 10
◆ 2GB Memory and 16GB Storage
◆ Front camera: 2MP, fixed focus ; Rear camera: 2MP, fixed focus
◆ 2400mAh Battery (Up to 4000mAh)
◆ 7" IPS TFT LCD, Resolution: 1024 x 600, Brightness: 280 cd/m2
◆ Wi-Fi 802.11 b/g/n + BT 4.0 (expandable)
◆ USB Type-C, Charging & data transmission supported

Description
Specifications
Documentation

Vantron M07 high-performance general-purpose industrial tablet is powered by Rockchip multi-core processor with a 7-inch capacitive touchscreen to offer excellent human-machine interaction experience. It runs Android system and has up to 2GB memory and 16GB storage to ensure high performance.


M07 supports cloud connectivity to Vantron BlueSphere device management platform for centralized management. In addition, it features flexible specification options, large battery capacity and outperforming power management system to meet different requirements for industrial application, making it a good choice of handheld device for application in medical terminals, self-service retailing system, multi-media education, libraries, and laboratories.

Specifications
CPU
Rockchip RK3326, Quad core, ARM Cortex-A35, 1.3GHz (Max)
GPU
Dvalin
Memory
2GB
Storage
16 GB 1 x Micro SD slot, up to 128GB
Wi-Fi & Bluetooth
Wi-Fi 802.11 b/g/n + BT 4.0 (Optional: Wi-Fi 802.11 ac/a/b/g/n + BT 5.0)
Display
7" IPS TFT LCD, Resolution: 1024 x 600, Brightness: 280 cd/m2
TP
5-point capacitive touch screen
Camera
Front camera: 2MP, fixed focus; Rear camera: 2MP, fixed focus
Audio
1 x 3.5mm combo audio jack 1 x 0.8W/8Ω speaker 1 x Mic
USB
1 x USB 2.0 Type-C (USB OTG supported)
Button
1 x Power on/off, 1 x Volume -/+
G-Sensor
Supported
RTC
Supported
OS
Android 10
Input
Type-C USB power input, 5V/2A DC
Battery
Single-cell Li-ion battery: 2400mAh/3.7V (Optional: 4000mAh/3.7V)
Dimensions
202.7mm x 113.2mm x 13.9mm
Temperature
Operating: 0℃~+45℃, Storage: -20℃~+45℃
Humidity
Operating: RH 20%-80% Storage: RH 20%-80%
Certification
FCC (Part 15 class B), ESD (contact: ±4KV and air: ±8KV)
Product Name
M07 7" Android General-purpose Industrial Tablet
Device management platform
BlueSphere MDM
OTA tool
BlueSphere OTA
Documentation
Vantron M07 7” General-purpose Industrial Tablet Datasheet - V2.4.pdf
M07 Industrial Tablet Datasheet
