M10R1-3588S-L 10" Android/Yocto Rugged Industrial Tablet

M10R1-3588S-L 10" Android/Yocto Rugged Industrial Tablet

◆ 4GB LPDDR4 + 64GB eMMC V5.1
◆ 8MP rear camera with LED flash
◆ IPS panel, 1920 x 1200, 400 nits
◆ NFC at 13.5MHz
◆ IP65, 1.5m drop test on 6 sides
◆ Pogo pin for flexible expansion
◆ USB Type-C, support data, DisplayPort, PD charge, etc.

Description

Specifications

Documentation

Vantron M10R1-3588S-L is a cost-optimized version of M10R1-3588S rugged industrial tablet, with reduced peripherals and a thinner profile. It is powered by a low-power high-performance octa-core processor, combined with ARM Mali-G610 MP4 GPU for 3D/2D graphic acceleration and a 6 TOPS NPU for industrial applications such as healthcare, plant walk-down, prison automation, and more.

M10R1-3588S-L features a 10-inch 16:10 IPS TFT LCD, with a resolution of up to 1920 x 1200 and a brightness of 400 nits to provide clear visuals even in bright sunlight or harsh lighting conditions. It is IP65-rated for water and dust resistance. Additionally, it has also been drop-tested from a height of 1.5m on all 6 sides, ensuring that it can withstand accidental drops and bumps without skipping a beat.

M10R1-3588S-L offers a pogo pin header to allow users to connect additional accessories or peripherals with ease. It supports up to 40W PD charging, ensuring quick and efficient charging when needed.

Specifications

Product Name

M10R1-3588S-L 10" Android/Yocto Rugged Industrial Tablet

CPU

Quad-core ARM Cortex-A76 MPCore processor + Quad-core ARM Cortex-A55 MPCore processor, Max. 2.4GHz

GPU

ARM Mali-G610 MP4, Max. 1GHz

NPU

6 TOPs

Memory

4GB LPDDR4

Storage

64GB eMMC V5.1

Wi-Fi & Bluetooth

Wi-Fi 802.11 a/b/g/n/ac/ax + BT 5.1

Cellular

2G/3G/4G, LTE CAT 4

GNSS

GPS + BeiDou + GLONASS + Galileo, A-GPS supported

NFC

Supported, 13.5MHz

Display

10” 16:10 IPS TFT LCD

Resolution

1920 x 1200

Color depth

16.7M

Brightness

400 nits

Contrast ratio

1000:1

Viewing angle

Horizontal: 85° / Vertical: 85°

10-point G + G PCAP touch screen

Finishing process

Toughening

Surface hardness

Rear camera

8MP, auto focus, with LED flash

Audio

1 x 8Ω/2w speaker ;1 x Mic

USB

1 x USB 3.0 Type-C, support data transfer, DisplayPort, PD charging, debugging

Pogo pin

2 x 10 pin, support 2 x USB 3.0, 100Mbps Ethernet RJ45, 3.5mm Combo audio Jack, 12V DC power input, 5V DC power output

SIM card slot

1 x Nano SIM slot

SD slot

1 x Micro SD slot (class 4 & class 10 supported, up to 128GB)

RTC

Supported

Watchdog timer

Supported

Sensor

1 x Light sensor; 1 x Gyro-sensor; 1 x G-sensor; 1 x Geomagnetic sensor 1 x TOF sensor

Button

1 x Volume+ button ; 1 x Volume- button; 1 x Power button

LED indicator

1 x Battery level indicator (Red: Low power; Amber: Charging; Green: Charged)

Android 13, Linux Yocto + QT

Input

USB Type-C power input, 5V/2A, 9V/2A, 12V/2A, 20V/2A, 40W PD charging supported

Battery

5000mAh/7.4V

Material

PC, ABS

Dimensions

273.8.6mm x 182.5mm x 24.9mm

Installation

VESA (75mm x 75mm)

Net weight

973g

IP rating

IP65

Drop testing

Drop from 1.5m onto concrete surfaces on 6 sides

MIL-STD-810H

Vibration, thermal shock, solar radiation, liquid pollution

Battery testing

UN38.3 MSDS Sea/Freight, IEC62133

Temperature

Operating: 0°C ~+60°C; Storage: -30°C ~+70°C

Humidity

20%~80% RH (Non-condensing)

Certification

MIL-STD-810H FCC (FCC Part 15 Class B); ISED, CE ESD (Contact: ±4KV, Air: ±8KV)

Documentation

Vantron M10R1-3588S-L 10“ Rugged Industrial Tablet Datasheet
